Free Bike Parking Plan

Embodies the lines of nature

CLICK BARS BELOW FOR SPECIFIC PRODUCT DETAILS.

Below are the Sol Bike Shelter drawings and specifications. Click on the links to access the details.

Sol 9’x10′

Sol 9’x16′

Sol 9’x25′

Sol 12’x10′

Sol 12’x16′

Sol 12’x25′

  • Multiwall translucent polycarbonate
  • Opal, clear, bronze – green or blue based on availability
  • Variety of custom colors available

  • Heavy gauge steel
  • 3-Coat Tnemec system including 2-part epoxy finish, galvanized or stainless steel
  • Anchor – surface mounted or below grade mounting kits
  • Zinc primer undercoat
  • PE Stamps available in all of North America
  • Custom colors available for no additional charge

  • Designed to address specific bike parking needs
  • Pre-engineered bike shelters
  • Constructed with readily available, standard materials
  • Cost-effective bicycle storage
  • Modular design, easily customizable

30″ Rack Spacing

9′ x 10’  6 Bikes
9′ x 13’  8 Bikes
9′ x 16′  10 Bikes
9′ x 19’  14 Bikes
9′ x 22’  16 Bikes
9′ x 25′  16 Bikes
9′ x 31’  20 Bikes
12′ x 13’  16 Bikes
12′ x 16’  20 Bikes
12′ x 19′  28 Bikes
12′ x 22’  32 Bikes
12′ x 25’  32 Bikes
12′ x 31′  40 Bikes

36″ Rack Spacing

9′ x 9’  6 Bikes
9′ x 13’  8 Bikes
9′ x 16′  10 Bikes
9′ x 19’  12 Bikes
9′ x 22’  14 Bikes
9′ x 25′  16 Bikes
9′ x 31’  20 Bikes
12′ x 13’ 16 Bikes
12′ x 16’  20 Bikes
12′ x 19′  24 Bikes
12′ x 22’  28 Bikes
12′ x 25’  32 Bikes
12′ x 31′  40 Bikes

Find out why we’ve been a leader and innovator in outdoor structures for over 30 years. Call and speak with one of our specialists at 734.207.9700 today.
