Reverse Barrel Vault Smoking Shelter

The reverse barrel vault style is a newer roof style that has become increasingly popular. We design, engineer and manufacture our reverse barrel vault roof shelters with a variety of durable materials. The roofing material can include standing seam metal, structured polycarbonate, solid polycarbonate or acrylic and laminated glass. Other roofing materials include standard shingles and textured roofing panels like Spanish tile.



Shelter Highlights

  • Designed for any smoke-free facility
  • 77 standard sizes – from 4′ x 4′ to 16′ x 37′

  • Custom sizes also available
  • Open, partially or fully enclosed
  • Wide array of roof styles & materials to choose from to fit site requirements
  • Broad range of amenities to outfit your shelter
  • Electrical packages completely pre-wired at our factory
  • Engineered to account for wind, snow and seismic loads
  • Engineer-stamped drawings available in all 50 states & Canada
  • Installation services are available in all fifty states



Reap The Benefits

  • Maintain clean & welcoming entryways
  • Present a positive corporate image
  • Direct smoking traffic to targeted areas
  • End doorway confrontations
  • Create a safe & secure, designated area for smokers
  • Provide a professional-looking alternative
  • Eliminate non-smokers’ concerns
  • Establish a year-round, long-term solution
  • Comply with codes & fire testing
  • Work within a budget tailored to your specific needs





Partner With An

Industry Pacesetter

  • Over a quarter century of shelter innovation
  • Unique architectural appeal
  • Designs to complement your existing building
  • Accommodation for site requirements

Cost-effective solutions
